Power and Drivetrain
- Motor: Equipped with a 48V 500W Brushless Rear Hub Motor that can reach a peak output of 750W. This provides strong, consistent power for city streets and moderate hills.
- Torque: Delivers 65 Nm of maximum torque, ensuring smooth acceleration and responsive hill-climbing assistance.
- Sensor Type: Utilizes a highly sensitive Torque Sensor. This technology measures the effort a rider puts into the pedals, resulting in instantaneous, natural-feeling motor assistance that is highly efficient and extends battery life.
- Battery & Range: Features a removable 48V 14Ah (672Wh) LG Lithium-Ion Battery. Riders can achieve an impressive maximum range of up to 72 miles on the lowest level of pedal assist, or approximately 38 miles on throttle-only use.
- Top Speed: Functions as a Class 2 e-bike with a top speed of 20 MPH (throttle and pedal assist). It can often be configured to Class 3 speed (28 MPH pedal assist), depending on local regulations.
- Gearing: A reliable Shimano 7-Speed Drivetrain (with TX50 shifter and TY300D derailleur) provides versatile gearing for adapting to different gradients and cruising speeds.
Design and Components
- Frame: Constructed from durable 6061 Aluminum Alloy in a non-folding, easy Step-Thru Frame style. The low 16.9″ standover height ensures comfortable mounting and dismounting, ideal for commuters with frequent stops or riders with limited mobility (recommended height 5’3″ to 6’2″).
- Suspension: Features a responsive EXSHO Suspension Front Fork to absorb shock and smooth out bumps on city streets and park trails.
- Brakes: Equipped with powerful Dual TEKTRO Mechanical Disc Brakes (180mm rotors) on the front and rear, providing reliable and consistent stopping power in all weather conditions.
- Tires: Rolls on 27.5″ x 2.0″ Anti-Puncture Reflective Tires, which are optimized for pavement and provide good grip, durability, and enhanced visibility.
- Display & Extras: A 3.5″ Full-Color, High-Brightness Display provides clear ride data at a glance. The bike comes fully accessorized with an Integrated LED Headlight and Brake Light, full-coverage Fenders, and a robust Rear Rack for carrying cargo.
- Capacity: Supports a maximum payload capacity of 300 lbs.
